SPECIFICATIONS

Brand Name: NoEnName_Null

Origin: Mainland China

Displacement: 50-100CC

Max. Speed: 40 - 60km/h

Motor: Other

Place of Origin: Zhejiang, China

Model Number: JIGGER[ FY50QT]-5

Overal Size LxWxH/mm: 1790X680X1150mm

Net Weight: 80KG

Optional Battery Set: 2 seats

Tire: Front/RearFront: 3.5-10/Rear: 3.5-10

Max Speed (km/h): 60km/h

Battery: 12V 7AH

Fuel Tank Capacity: 4.2L

Max Power: 2.4kw / 8000r/min

Max.torque: 2.8Nm / 6500r/min

Engine Type: 1-Cylinder.4-Stroke.air-cooled

Products Description

>>>More Product Related Information<<<

Contact Us

Model	JIGGER[ FY50QT]
Engine	Engine model	139QMB
		Engine Type	1-Cylinder.4-Stroke.air-cooled
		Displacement	49.3cc
		Ignition	CDI
		Compression ratio	10.5:1
		Certified	EPA JIGGER
Motorcycle Body	Brake	Front: disk/Rear: drum
		Front Suspension	hydraulic suspension
		Rear Absorber	Double
		Wheel Base	1260mm
		Tyre Size	Front: 3.50-10/Rear: 3.50-10
		Wheel Atmosphere	Front & Rear: 220/250kPa
		Fuel mode	Gasoline
		Oil Supply Way	carburetor
		Dimension	1790X680X1150mm
		Net Weight(kg)	80kg
Performance	Max Power	2.4kw / 8000r/min
		Max.torque	2.8Nm / 6500r/min
		Max Load	150kg
		Max Speed	60km/h
	Fuel tank capacity	4.2L
	Battery	12V7Ah
Loading Qty	Loading Quantity	105HQ
		Packing Type	Carton with steel bracket



Our Service

1. OEM Manufacturing welcome: Product, Package... 2. Sample order 3. We will reply you for your inquiry in 24 hours. 4. after sending, we will track the products for you once every two days, until you get the products. When you got thegoods, test them, and give me a feedback.If you have any questions about the problem, contact with us, we will offerthe solve way for you.
